产品名称Products Series贯穿式端子/ Feed Through Terminal产品型号 Series NumberMF35-120-046测试标准(Test standard)UL1059 / IEC60998-1产品间距（Pitch）[ mm ]12.0极数（Poles）2P~12PUL Test Data应用组别(Use group)BCD额定电压(Rated voltage) [ V ]300//额定电流(Rated current) [ A ]35//额定接线范围 (Rated connection capacity) (solid/stranded) [AWG]10~22IEC Test Data污染等级(Contamination Class)ⅢⅢⅡ过压类别(Surge voltage category)3//额定电压(Rated voltage) [ V ]500//额定电流(Rated current) [ A ]41//额定冲击电压(Rate Surge Voltage) [ KV ]2//额定接线范围 (Rated connection capacity) (solid/stranded) [ mm²]2.5~6.0通用数据(General data)阻燃等级(Inflammability class)UL94V-2环境温度(Operation temperature) [℃]-35℃～+110℃相对湿度(Relative humidity)5%~95%螺丝(Screw)M3.5材质、镀层(Material and plating)绝缘材质(Housing)尼龙66 （ PA66 ）螺丝(Screws / plating)钢/镀锌（Steel / Zinc plated）导电板(Current connector )黄铜/镀镍 （Brass / Nickel Plated）弹片(Wire protector)不锈钢 （Stainless steel）尺寸图纸Drawing
How to order
X X X X – X X X – X X X X X
Series no Model no. poles color special demand
How to order：MF35 – 120 – X X X X X
POLES COLOR Special
02 2poles 1 Green 绿 空白为标准品
03 3poles 2 Black 黑 XX 为非标准
04 4poles 3 Grey 灰
….. 4 Blue 蓝
12 12poles 5 Red 红
6 White 白
7 Yellow黄
8 Purple 紫
